Canadian TOPCon 580-610W BIFACIAL MONO PERC BiHiKu7-CS7L Solar Thermal Hybrid Panel

Brand Name: CanadianSolar
Model Number: BiHiKu7-CS7L 580-610W
MOQ: 10000 watts
Price: $0.13/watts >=10000 watts
Detail Information
Product Description
Detail Information
Place of Origin:
Anhui, China
Cell Size:
210mmx210mm
Type:
PERC, Bifacial
Panel Dimensions:
2172*1303*33
Panel Efficiency:
20.5-21.6%
Warranty:
25years
Totipotent:
Photovoltaic Panel
Cell Type:
TOPCon Cells
Cell Arrangement:
120 [2 X (10 X 6) ]
Dimensions:
2172*1303*33
Weight:
34.5 Kg (76.1 Lbs)
Frame:
Anodized Aluminium Alloy
Junction Box:
IP68,3 Bypass Diodes
Connector:
T6 Or MC4-EVO2 Or MC4-EVO2A
Maximum System Voltage:
1500 V (IEC/UL) Or 1000 V (IEC/UL)
Maximum Series Fuse Rating:
35A
Product Description
Products Description
Canadian TOPCon 580-610W BIFACIAL MONO PERC BiHiKu7-CS7L Solar Thermal Hybrid Panel 0
Canadian TOPCon 580-610W BIFACIAL MONO PERC BiHiKu7-CS7L Solar Thermal Hybrid Panel 1
Canadian TOPCon 580-610W BIFACIAL MONO PERC BiHiKu7-CS7L Solar Thermal Hybrid Panel 2
Cell Type
Mono-crystalline
Cell Arrangement
120 [2 x (10 x 6) ]
Dimensions
2172 ˣ 1303 ˣ 33 mm (85.5 ˣ 51.3 ˣ 1.30 in)
Weight
34.5 kg (76.1 lbs)
Front Glass
2.0 mm heat strengthened glass with antireflective coating
Back Glass
2.0 mm heat strengthened glass
Frame
Anodized aluminium alloy
J-Box
IP68, 3 bypass diodes
Cable
4.0 mm² (IEC), 10 AWG (UL)
Cable Length
(Including Connector)
360 mm (14.2 in) (+) / 200 mm (7.9 in) (-) or
customized length*
Connector
T6 or MC4-EVO2 or MC4-EVO2A
Per Pallet
33 pieces
Per Container (40' HQ)
594 pieces or 528 pieces (only for US & Canada)
