Good price online

products details

Home > Products >
Solar PV Panel
>
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater
All Category

Solar PV Panel

Sunrise

Canadian

JA

Jinko

Trina

Longi

Solar Battery

Stackable Solar Battery

Rack Mounted Solar Battery

Wall Mounted Solar Battery

Solar Inverter

Deye Solar Inverter

Goodwe Solar Inverter

Huawei Solar Inverter

Growatt Solar Inverter

PV system
Contact Us
Miss. Airey Chen
airey@hefeisunrise.com
+86-13966396843
wechat 13966396843
Contact Now
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater
  • name
  • name
  • name
  • name
  • name
  • name

N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater

Brand Name: JinKoSolar
Model Number: Tiger Neo 54HL4-V 470W-490W
MOQ: 10000 watts
Price: $0.13/watts >=10000 watts
Detail Information
Product Description
Detail Information
Place of Origin:
Anhui, China
Cell Size:
210mmx210mm
Type:
N-TYPE
Panel Dimensions:
1906*1134*30
Panel Efficiency:
21.27-22.27%
Warranty:
25years
Totipotent:
Photovoltaic Panel
Cell Type:
N -type Mono-crystalline
Cell Arrangement:
120 (60x2)
Dimensions:
1906*1134*30
Weight:
22.5 Kg
Frame:
Anodized Aluminium Alloy
Junction Box:
LP68 Rated
Protection Class:
Class II
Maximum System Voltage:
1000/1500 VDC (lEC)
Maximum Series Fuse Rating:
25A
Product Description
Products Description
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 0
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 1
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 2
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 3
Cell Type
N -type Mono-crystalline
No. of cells
120 (60x2)
Dimensions
1906x1134x30mm
Weight
22.5 kg
Front Glass
3.2 mm, Anti-Relection coating,
High Transmission, Low lron, Tempered Glass
Frame
Anodized Aluminium Alloy
Junction Box
lP68 Rated
protection class
Class ll
IEC Fire Type
Class C
0utput Cables
4.0 mm² （+）: 400 mm ,（-）: 200 mm or Customized Length
Pallet Dimensions
1936x1140x1249 mm
Packing Detail （ Two pallets = One stack ）
37 pcs/pallets, 74pcs/stack, 888 pcs/ 40'HQ container
Our Products
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 4
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 5
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 6
Global Pipeline in Key Regions
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 7
Featured Projects
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 8
Product packaging
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 9
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 10
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 11
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 12
Application program
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 13
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 14
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 15
Company Profile
Hefei Sunrise New Energy Co.,Ltd is a professional and fast growing company with more than 10 years experience in New energy field, located in Hefei city ,Anhui province .Our company is committed to high efficient and clean energy research and development ,and bring quick & professional service to our customers in all aspects of solar products and projects.
Being the top distributor of Tier 1 solar product brands including Longi, Sungrow, Trina, JA, Canadian, Growatt, Goodwe, Sunrise provides not only solar panels and solar inverters,but also system integration for on-grid systems, off-grid systems, energy storage systems, etc.
Our products have been sold to many countries and regions in Europe, North America, the Middle East and South Africa,etc. also have got certificates of TUV, CE, CQC , etc .
To complete the most intimate cooperation, We will provide customers with the best quality products & service,and sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation .

N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 16
N-Type Mono-Crystalline 470W-490W Solar Panel for JinKo Solar Hot Water System Heater 17
FAQ
1. What is your main products?
Our main products including Solar Panel, Inverter, Battery,Solar System, Mounting System and other related Solar Power Accessories;

2. Are you a factory or trading company ?
We are a professional Solar energy products manufacturer in China with own factory and the advanced production line ,can ensure superior supply capacity.

3.How can you guarantee your product quality ?
We will provide a pre-production sample before mass production, Each product will after several inspection procedures before shipment;

4.Could you print our company logo in nameplate and package ?
Yes ,we can customized your logo according to your design and request;

5. What if I don't have export experience ?
We have reliable forwarder agent which can ship items to you by Sea/Air/Express to your seaport or doorstep.Anyway, we will help you choose the most suitable shipping service.
