Brand Name: | Canadian |
Model Number: | TOPHiKu6_CS6.1-72TD-595-625w |
MOQ: | 10000 watts |
Price: | $0.11/watts 10000-49999 watts |
Mechanical Characteristics | ||||||||
Cell type | N-Type TOPCon Mono cells | |||||||
Cell Arrangement | 144 [2 x (12 x 6) ] | |||||||
Module Dimension | 2382 ˣ 1134 ˣ 30 mm | |||||||
Module Weight | 33.6 kg | |||||||
Front Glass | 2.0 mm (0.08 inches), AR Coated Heat Strengthened Glass | |||||||
Back Glass | 2.0 mm (0.08 inches), Heat Strengthened Glass | |||||||
Junction Box | IP68, 3 bypass diodes | |||||||
Cable | 4.0 mm² (IEC), 12 AWG (UL) | |||||||
Cable Length (Including Connector) | 300 mm (11.8 in) (+) / 200 mm (7.9 in) (-) or customized length* | |||||||
Connector | T6 or MC4-EVO2 or MC4-EVO2A |
